| Параметр | Значение |
| Общие характеристики | |
| Артикул | 2219 |
| MTTF | 750 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Operating voltage | 10 ... 30 V DC |
| No-load supply current | ≤ 20 mA |
| Switching frequency | 0 ... 10 Hz |
| UL approval | cULus Listed, General Purpose |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) |
| Degree of protection | IP65 |
| Voltage drop | ≤ 3 V |
| Note | Tightening torque: 1.8 Nm (housing) |
| Operating current | 0 ... 200 mA |
| Output type | 4-wire |
| Switching function | complementary |
| Rated operating distance | 15 mm |
| Installation | flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 10.8 mm |
| B | 15 mm |
| C | 30 mm |
| F | 80 mm |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| CSA approval | cCSAus Listed, General Purpose |
| Connection type | screw terminals |
| Housing material | PBT |
| Sensing face | PBT |
| Core cross-section | up to 2.5 mm |
| Operating voltage indicator | LED, green |
| Information for connection | A maximum of two conductors with the same core cross section may be mounted on one terminal connection! tightening torque 1.2 Nm + 10 % |
| Minimum core cross-section | without wire end ferrule 0.5 mm , with connector sleeves 0.34 mm |
| Maximum core cross-section | without wire end ferrule 2.5 mm , with connector sleeves 1.5 mm |
