| Параметр | Значение |
| Общие характеристики | |
| Артикул | 89201 |
| MTTF | 140 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Operating voltage | 4.75 ... 30 V DC |
| No-load supply current | max. 50 mA |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Degree of protection | DIN EN 60529, IP65, IP67 |
| Housing | nickel-plated steel , painted |
| Mass | ca 300 g |
| Linearity error | ± 0.1 ° |
| Cable | ∅6 mm, 4 x 2 x 0.14 mm |
| Output type | HTL/TTL configurable |
| Vibration resistance | DIN EN 60068-2-6, 10 , 10 ... 1000 Hz |
| Connector | M12 connector, 8-pin M12 connector, 5 pin M23 connector, 12-pin |
| Default setting | output type HTL , pulse count 1024 , direction of rotation A before B (clockwise) |
| Pulse count | configurable from 1 ... 16384 |
| Load current | max. per channel 50 mA , short-circuit protected, reverse polarity protected |
| Output frequency | max. 1000 kHz |
| Rise time | 300 ns |
| Climatic testing | DIN EN 60068-2-78 , no moisture condensation |
| Emitted interference | EN 61000-6-4:2007/A1:2011 |
| Noise immunity | EN 61000-6-2:2005 |
| Rotational speed | max. 3000 min |
| Moment of inertia | ≤ 30 gcm |
| Starting torque | ≤ 3 Ncm for IP65 , ≤ 5 Ncm for IP67 |
| Axial | max. 40 N |
| Radial | max. 110 N |
| Shock resistance | DIN EN 60068-2-27, 100 , 6 ms |
| Operating temperature | cable, flexing: -5 ... 70 °C (23 ... 158 °F) cable, fixed: -30 ... 70 °C (-22 ... 158 °F) connector models: -40 ... 85 °C (-40 ... 185 °F) |
| L | 70 E+9 at 6000 rpm |
| Detection type | magnetic sampling |
| Flange | Aluminum |
| Shaft | Stainless steel |
| Duty cycle | 1/2 ± 15 % for speed > 100 min |
| Phase position A to B | 90 ° ± 14 ° for speed > 100 min |
