Incremental rotary encoder MNI40N-0T01DY41N-01000 86542

Name: Incremental rotary encoder MNI40N-0T01DY41N-01000
SKU: 86542
Availability: PreOrder

Для оформления заявки добавьте оборудование
в корзину и сформируйте заказ

артикул: 86542

Под заказ

Запрос цены

В избранное Сравнить

Цены носят информационный характер и не являются публичной офертой. Точную цену и срок поставки подтвердит менеджер при оформлении заявки

Доставка в любой регион России транспортной
компанией на Ваш выбор

Clear function verification via two-color LEDs (red/green)
Simple installation and adjustment using assistance functions reduce costs
Self-diagnostics including the magnetic wheel provide quality assurance
Internal intelligence provides easy setup and reliable operation
The elastomer coating of the magnetic wheel provides resistance to dirt as well as thermal and mechanical shock
Long service life at high speeds and temperatures

Параметр	Значение
Общие характеристики
Артикул	86542
MTTF	942 a
Mission Time (T	20 a
Diagnostic Coverage (DC)	0 %
Operating voltage	10 ... 30 V DC
No-load supply current	max. 55 mA
UL approval	cULus Listed, General Purpose, Class 2 Power Source, Type 1 enclosure , if UL marking is marked on the product. adapters providing field wiring on request
Storage temperature	-40 ... 100 °C (-40 ... 212 °F)
Degree of protection	DIN EN 60529, IP67 , IP68 , IP69K
Housing	PA
Mass	approx. 190 g
Voltage drop	< 2.5 V
Cable	PUR
Output type	push-pull, incremental
Vibration resistance	DIN EN 60068-2-6, 40 , 10 ... 2000 Hz
Connector	L = 0.3 m fixed cable with Deutsch connector DTM04-6P
Pulse count	1000
Load current	max. per channel 30 mA , short-circuit protected
Output frequency	max. 1 MHz
Climatic testing	DIN EN 60068-2-30
Emitted interference	EN 61000-6-4:2007/A1:2011
Noise immunity	EN 61000-6-2:2005
Rotational speed	max. 30000 min
Shock resistance	DIN EN 60068-2-27, 200 , 6 ms
Operating temperature	-40 ... 100 °C (-40 ... 212 °F)
Maximum permissible ambient temperature	max. 75 °C (max. 167 °F)
UL File Number	E223176 "For use in NFPA 79 Applications only" , if UL marking is marked on the product.
LED red/green	Operating display / Alignment aid
Detection type	magnetic sampling
Magnetic wheel	steel 1.4021 (AISI 420) ferrite filled cured rubber
