| Параметр | Значение |
| Общие характеристики | |
| Артикул | 83671 |
| MTTF | 140 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Operating voltage | 4.75 ... 30 V DC |
| No-load supply current | max. 50 mA |
| UL approval | cULus Listed, General Purpose, Class 2 Power Source, Type 1 enclosure , if UL marking is marked on the product. adapters providing field wiring on request |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Degree of protection | DIN EN 60529, IP65, IP67 |
| Housing | 3.2315 aluminum (AlMgSi1, saltwater-proof) |
| Mass | < 400 g without cable |
| Linearity error | ± 0.025 ° |
| Cable | ∅6 mm, 4 x 2 x 0.14 mm Fixed cable with M12 plug. 5-pin Fixed cable with M12 plug. 8-pin |
| Output type | push-pull or RS422 (universal output driver, output level depending on input voltage) |
| Vibration resistance | DIN EN 60068-2-6, 30 , 10 ... 2000 Hz |
| Connector | M12 connector, 8-pin M12 connector, 5 pin M23 connector, 12-pin 10-pin MIL connector 7-pin MIL connector |
| Pulse count | max. 5000 |
| Load current | max. per channel 40 mA , short-circuit protected, reverse polarity protected |
| Output frequency | max. 400 kHz |
| Rise time | 300 ns |
| Climatic testing | DIN EN 60068-2-78 , no moisture condensation |
| Emitted interference | EN 61000-6-4:2007/A1:2011 |
| Noise immunity | EN 61000-6-2:2005 |
| Rotational speed | max. 12000 min for IP65 , max. 6000 min for IP67 |
| Moment of inertia | ≤ 35 gcm |
| Starting torque | ≤ 1.5 Ncm |
| Axial | 40 N at max. 6000 min 10 N at max. 12000 min |
| Radial | 80 N at max. 6000 min 20 N at max. 12000 min |
| Shock resistance | DIN EN 60068-2-27, 300 , 6 ms |
| Operating temperature | -40 ... 85 °C (-40 ... 185 °F) , fixed cable -5 ... 85 °C (23 ... 185 °F) , movable cable |
| L | 70 E+9 at 6000 rpm |
| Maximum permissible ambient temperature | max. 80 °C (max. 176 °F) |
| UL File Number | E223176 "For use in NFPA 79 Applications only" , if UL marking is marked on the product. |
| Detection type | photoelectric sampling |
| Flange | 3.2315 aluminum (AlMgSi1, saltwater-proof) |
| Shaft | Solid shaft Stainless steel |
| Pulse counts < 3600 | 90 ° ± 9 ° electrical |
| Pulse counts ≥ 3600 | 90 ° ± 15 ° electrical |
| Duty cycle | 1/2 ± 10 % |
