| Параметр | Значение |
| Общие характеристики | |
| Артикул | 64459 |
| MTTF | 140 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Operating voltage | 10 ... 30 V DC or 5 V DC ± 5 % (see "Output circuit" in the ordering information) |
| No-load supply current | max. 70 mA |
| Storage temperature | -40 ... 80 °C (-40 ... 176 °F) |
| Degree of protection | DIN EN 60529, IP66, IP67 or IP69K |
| Housing | 3.2315 aluminum |
| Mass | approx. 2200 g |
| Voltage drop | < 2.5 V (push-pull, incremental) |
| Cable | ∅6.5 mm, 4 x 2 x 0.14 mm |
| Output type | push-pull, incremental or RS 422, incremental (see "Output circuit" in the ordering information) |
| Vibration resistance | DIN EN 60068-2-6, 20 , 10 ... 2000 Hz |
| Connector | M23 connector, 12-pin , clockwise rotation M23 connector, 12-pin , counter clockwise rotation |
| Pulse count | max. 2500 |
| Load current | max. per channel 40 mA , short-circuit protected, reverse polarity protected (push-pull, incremental) max. per channel 20 mA , short-circuit protected, reverse polarity protected (RS 422, incremental) |
| Output frequency | max. 200 kHz |
| Rise time | 600 ns |
| De-energized delay | 600 ns |
| Climatic testing | DIN EN 60068-2-78 , no moisture condensation |
| Emitted interference | EN 61000-6-4:2007 |
| Noise immunity | EN 61000-6-2:2005 |
| Rotational speed | max. 3000 min |
| Starting torque | ≤ 10 Ncm |
| Axial | ≤ 300 N |
| Radial | ≤ 400 N |
| Shock resistance | DIN EN 60068-2-27, 200 , 6 ms |
| Operating temperature | -40 ... 80 °C (-40 ... 176 °F) fixed cable |
| L | 50 E+9 at 1750 rpm |
| Detection type | photoelectric sampling |
| Flange | 3.2315 aluminum |
| Shaft | Stainless steel 1.4305 / AISI 303 |
| Angle offset | 1 ° |
| Axial offset | max. 1 mm |
| Terminal compartment | Cable duct for cable diameter ∅4 mm ... 13 mm |
