Incremental rotary encoder RVS58S-YYYKYA6ZT-01024 44496

Name: Incremental rotary encoder RVS58S-YYYKYA6ZT-01024
SKU: 44496
Availability: PreOrder

Для оформления заявки добавьте оборудование
в корзину и сформируйте заказ

артикул: 44496

Под заказ

Запрос цены

В избранное Сравнить

Цены носят информационный характер и не являются публичной офертой. Точную цену и срок поставки подтвердит менеджер при оформлении заявки

Доставка в любой регион России транспортной
компанией на Ваш выбор

Safe rotary encoder, thanks to integrated functional safety
Usable up to SIL 3 acc. to IEC 61508
TÜV certified
Suitable as motor feedback system for safe drives in accordance with IEC 61800-5-2
Incremental encoder with sin/cos interface
1024 or 2048 signal periods
Thermally stabilized with the highest precision for high resolution interpolation

Параметр	Значение
Общие характеристики
Артикул	44496
MTTF	1000 a
Mission Time (T	20 a
Diagnostic Coverage (DC)	98 %
Operating voltage	5 V DC ± 5 %
No-load supply current	max. 70 mA
UL approval	cULus Recognized, General Purpose, Class 2 Power Source
Storage temperature	-40 ... 100 °C (-40 ... 212 °F)
Degree of protection	DIN EN 60529, IP40
Housing	aluminum, blank
Mass	approx. 350 g
Cable	Single stranded wires with crimp contact, 10 x AWG26, 230 mm
Output type	sine / cosine
Vibration resistance	DIN EN 60068-2-6, 20 g, 55 ... 2000 Hz
Pulse count	1024 and 2048
Load current	max. per channel 10 mA , short-circuit protected, reverse polarity protected
Output frequency	max. 200 kHz (3 dB limit)
Climatic testing	DIN EN 60068-2-78 , no moisture condensation
Emitted interference	EN 61000-6-4:2007/A1:2011
Noise immunity	DIN EN 61000-6-2 , advanced testing level to IEC 61326-3-1
Rotational speed	max. 8000 min
Moment of inertia	≤ 25 gcm
Starting torque	≤ 1.5 Ncm
Axial	40 N at max. 6000 rpm 10 N at max. 8000 rpm
Radial	at 60 N max. 6000 rpm at 20 N max. 8000 rpm
Shock resistance	DIN EN 60068-2-27, 100 , 3 ms
Operating temperature	-20 ... 115 °C (-4 ... 239 °F) , fixed cable
Safety Integrity Level (SIL)	SIL 3
L	7.5 E+9 at 6000 rpm
Performance level (PL)	PL e
Functional safety	IEC 61508:2010 (SIL3) IEC 62061:2012 ISO 13849-1:2015 IEC 61800-5-2:2007 EN 50178:1997 IEC 61326-3-1:2007 Suitable up to SIL 3, PL e depending from configuration, see instruction leaflet
TÜV approval	Cert. no. Z10 068273 0003
PFH	2.41 E-9
Flange	3.1655 aluminum
Shaft	Stainless steel 1.4305 / AISI 303
Amplitude	1 V ± 10 %
