| Параметр | Значение |
| Общие характеристики | |
| Артикул | 25560 |
| MTTF | 4382 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Switching frequency | 0 ... 5000 Hz |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) |
| Degree of protection | IP66 / IP67 |
| Output type | 2-wire |
| Switching function | Normally open (NO) |
| Rated operating distance | 60 mm |
| Installation | flush in non-magnetic metal |
| Assured operating distance | 10 ... 48.6 mm |
| Switching state indicator | LED, yellow |
| Connection type | cable PVC , 2 m |
| Housing material | stainless steel 1.4404 / AISI 316L |
| Sensing face | stainless steel 1.4404 / AISI 316L |
| Standards | EN 60079-0:2012+A11:2013, EN 60079-11:2012 Ignition protection "Intrinsic safety" Use is restricted to the following stated conditions |
| Core cross-section | 0.34 mm |
| CE marking | [*PD-Z02585A*] |
| Control drawing | 116-0165 |
| Nominal voltage | 8.2 V (R approx. 1 kΩ) |
| Magnet detected | ≥ 2.5 mA |
| Magnet not detected | ≤ 1 mA |
| NAMUR | EN 60947-5-6:2000 |
| ATEX marking | II 2G Ex ib IIC T6 Gb |
| Appropriate type | MC60-12GM50-1N |
| Effective internal capacitance | max. 15 nF ; a cable length of 10 m is considered. |
| Effective internal inductance | max. 35 µH ; a cable length of 10 m is considered. |
| Use in the hazardous area | see instruction manuals |
| Category | 2G |
