| Параметр | Значение |
| Общие характеристики | |
| Артикул | 58341 |
| MTTF | 1134 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Operating voltage | 5 ... 15 V |
| Switching frequency | 0 ... 50 Hz |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient temperature | -20 ... 70 °C (-4 ... 158 °F) |
| Degree of protection | IP67 |
| Output type | 2-wire |
| Switching function | Normally open (NO) |
| Rated operating distance | 10 mm |
| Installation | flush |
| A | 0 mm |
| B | 0 mm |
| C | 20 mm |
| F | 60 mm |
| Reverse polarity protection | reverse polarity protected |
| Switching state indicator | LED, yellow |
| Connection type | Connector plug M12 x 1 , 4-pin |
| Housing material | Stainless steel 1.4305 / AISI 303 |
| Sensing face | PTFE |
| Standards | EN 60079-0:2012; EN 60079-11:2012 type of protection intrinsic safety "ia" |
| CE marking | [*PD-Z02585A*] |
| Nominal voltage | 8.2 V (R approx. 1 kΩ) |
| NAMUR | EN 60947-5-6:2000 IEC 60947-5-6:1999 |
| ATEX marking | II 1D Ex ia IIIC T101°C Da |
| Appropriate type | CCB10-30GS55-N1... |
| Effective internal capacitance | max. 250 nF |
| Effective internal inductance | max. 200 µH |
| Use in the hazardous area | see instruction manuals |
| Category | 1G; 1D |
| Measuring plate not detected | ≤ 1.5 mA |
| Measuring plate detected | ≥ 2.5 mA |
| ETL approval | cETLus |
| T6 when Pi = 100 mW, Ui = 15 V, Ii =30 mA | 40 °C (104 °F) |
| T5 when Pi = 100 mW, Ui = 15 V, li = 30 mA | 40 °C (104 °F) |
| T4 when Pi = 100 mW, Ui = 15 V, Ii = 30 mA | 80 °C (176 °F) |
| T3, T2, T1 when Pi = 100 mW, Ui = 15 V, Ii = 30 mA | 100 °C (212 °F) |
