| Параметр | Значение |
| Общие характеристики | |
| Артикул | 1884 |
| MTTF | 1210 a |
| Mission Time (T | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Operating voltage | 10 ... 30 V DC |
| No-load supply current | ≤ 15 mA |
| Switching frequency | 0 ... 5 Hz |
| UL approval | cULus Listed, General Purpose |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient temperature | -25 ... 70 °C (-13 ... 158 °F) |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Degree of protection | IP67 |
| Time delay before availability | ≤ 50 ms |
| Voltage drop | ≤ 2 V |
| Operating current | 0 ... 100 mA |
| Bending radius | > 10 x cable diameter |
| Output type | 3-wire |
| Cable diameter | 3.5 mm ± 0.2 mm |
| Switching function | Normally open (NO) |
| Rated operating distance | 10 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 7 mm |
| B | 5 mm |
| C | 20 mm |
| F | 20 mm / 50 mm |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Switching state indicator | LED, yellow |
| CSA approval | cCSAus Listed, General Purpose |
| Connection type | cable PVC , 2 m |
| Housing material | PBT |
| Sensing face | PBT |
| Hysteresis | 1 ... 10 typ. 5 % |
| Voltage drop I | 0.8 ... 2.2 V typ. 1.4 V |
| Lowest operating current | 0 mA |
| Off-state current | 0 ... 0.5 mA typ. 0.01 mA |
| Off-state current T | ≤ 100 µA |
| Standards | EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 |
| Core cross-section | 0.14 mm |
